FPS002 Product Data Book

Gantong brand air pressure automatic control switch, advanced technology, excellent products. This product realizes the automation of operation, not only saves manpower and resources, but also extends the service life of the machine,At the same time, we also provide some accessories for this product, which you can use according to your needs...

Previous Next

Specs FPSS002;Look| Download

Description
1. Product model：FPSS002
2. Measured mile: Air
3. Operating Temperature Range: -40 to 70℃
4. Overpressure : 14”W.C
5. The altitude less than 500m
6. Life: 100,000 Cycles Minimum
7. Inductive load and grounding protection
8. Mounting Posltion:Vertical/Horizontal
9. Control pollution degree: pollution 2
10. Rated impulse voltage : Overvoltage Category II
11. Type of load and power factor：Circuit suitable for either a resistive load or for an inductive load
Electrical parameters
1． Operating Voltage Range：120VAC 50/60 Hz
2． Electrical Load: 3A@120Vac,50/60Hz
3． Screw connector,Clamp Type Terminal Block Sultable for 12~26AWG
Operational principle
1 . Timer Operation: Recycling Delay Timer with 10 Min.ON,15 Sec.OFF Cycle.
2. As Differential Pressure Exceeds Set Point:the Snap Switch NC Contact Disconnect,signaling the Micropocessor that the Air Switch has Changed State. The Microprocessor Will Energize the Relay and Start the Timing Sequence
3.adjustable air pressure trip point setting by turn the screw TAP
